MM70-314B2-1-R500

Image is for reference, please contact us to get the real picture

Part No :: MM70-314B2-1-R500

Manufacturer: JAE Electronics

Description: CONN MXM FMALE 314POS 0.020 GOLD

Catalog: Card Edge Connectors - Edgeboard Connectors

Availability: 592559 pieces

Shipped from: HK warehouse

Expected Shipping Date: Jul 13 - Jul 17 2025

PDF: MM70-314B2-1-R500 PDF

Type	Description
Series:	MM70
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Obsolete
Card Type:	MXM 3.0
Gender:	Female
Number of Positions/Bay/Row:	-
Number of Positions:	314
Card Thickness:	0.047" (1.20mm)
Number of Rows:	2
Pitch:	0.020" (0.50mm)
Read Out:	Dual
Features:	-
Mounting Type:	Surface Mount, Right Angle
Termination:	Solder
Contact Material:	Copper Alloy
Contact Finish:	Gold
Contact Finish Thickness:	11.8µin (0.30µm)
Contact Type:	-
Color:	Black
Flange Feature:	-
Operating Temperature:	-40°C ~ 85°C
