1054292304

1054292304

Image is for reference, please contact us to get the real picture

Part No :

1054292304

Manufacturer
Woodhead - Molex
Description
NANO-FIT HDR SMT VT DLR 4CKT 30A
Catalog
Rectangular Connectors - Headers, Male Pins
Availability
721872 pieces
Shipped from
HK warehouse
Expected Shipping Date
Jul 15 - Jul 19 2025
Type Description
Series:Nano-Fit 105429
Package:Tape & Reel (TR)
Part Status:Active
Connector Type:Header
Contact Type:Male Pin
Pitch - Mating:0.098" (2.50mm)
Number of Positions:4
Number of Rows:2
Row Spacing - Mating:0.098" (2.50mm)
Number of Positions Loaded:All
Style:Board to Cable/Wire
Shrouding:Shrouded - 4 Wall
Mounting Type:Surface Mount
Termination:Solder
Fastening Type:Latch Holder
Contact Length - Mating:-
Contact Length - Post:-
Overall Contact Length:-
Insulation Height:0.382" (9.70mm)
Contact Shape:Square
Contact Finish - Mating:Gold
Contact Finish Thickness - Mating:30.0µin (0.76µm)
Contact Finish - Post:Tin
Contact Material:Brass
Insulation Material:Liquid Crystal Polymer (LCP)
Features:Pick and Place
Operating Temperature:-40°C ~ 115°C
Ingress Protection:-
Material Flammability Rating:UL94 V-0
Insulation Color:Natural
Current Rating (Amps):4A
Voltage Rating:250VAC
1054292304 is available at GangBo-ic.com, Please review product page below for detailed information, including 1054292304 price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for 1054292304 to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
