IPL1-110-01-S-D-RA-K

IPL1-110-01-S-D-RA-K

Image is for reference, please contact us to get the real picture

Part No :

IPL1-110-01-S-D-RA-K

Manufacturer
Samtec, Inc.
Description
CONN HEADER R/A 20POS 2.54MM
Catalog
Rectangular Connectors - Headers, Male Pins
Availability
10125 pieces
Shipped from
HK warehouse
Expected Shipping Date
Jul 29 - Aug 02 2025
PDF
IPL1-110-01-S-D-RA-K PDF
Type Description
Series:Mini Mate® IPL1
Package:Tube
Part Status:Active
Connector Type:Header
Contact Type:Male Pin
Pitch - Mating:0.100" (2.54mm)
Number of Positions:20
Number of Rows:2
Row Spacing - Mating:0.100" (2.54mm)
Number of Positions Loaded:All
Style:Board to Cable/Wire
Shrouding:Shrouded - 4 Wall
Mounting Type:Through Hole, Right Angle
Termination:Solder
Fastening Type:Locking Ramp
Contact Length - Mating:0.215" (5.46mm)
Contact Length - Post:0.085" (2.16mm)
Overall Contact Length:-
Insulation Height:0.290" (7.37mm)
Contact Shape:Square
Contact Finish - Mating:Gold
Contact Finish Thickness - Mating:30.0µin (0.76µm)
Contact Finish - Post:Tin
Contact Material:Phosphor Bronze
Insulation Material:Liquid Crystal Polymer (LCP)
Features:-
Operating Temperature:-55°C ~ 125°C
Ingress Protection:-
Material Flammability Rating:UL94 V-0
Insulation Color:Natural
Current Rating (Amps):-
Voltage Rating:675VAC, 954VDC
IPL1-110-01-S-D-RA-K is available at GangBo-ic.com, Please review product page below for detailed information, including IPL1-110-01-S-D-RA-K price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for IPL1-110-01-S-D-RA-K to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
