TMM-147-01-S-S

TMM-147-01-S-S

Image is for reference, please contact us to get the real picture

Part No :

TMM-147-01-S-S

Manufacturer
Samtec, Inc.
Description
CONN HEADER VERT 47POS 2MM
Catalog
Rectangular Connectors - Headers, Male Pins
Availability
142114 pieces
Shipped from
HK warehouse
Expected Shipping Date
Nov 09 - Nov 13 2025
PDF
TMM-147-01-S-S PDF
Type Description
Series:TMM
Package:Bulk
Part Status:Discontinued at Digi-Key
Connector Type:Header
Contact Type:Male Pin
Pitch - Mating:0.079" (2.00mm)
Number of Positions:47
Number of Rows:1
Row Spacing - Mating:-
Number of Positions Loaded:All
Style:Board to Board or Cable
Shrouding:Unshrouded
Mounting Type:Through Hole
Termination:Solder
Fastening Type:Push-Pull
Contact Length - Mating:0.126" (3.20mm)
Contact Length - Post:0.138" (3.50mm)
Overall Contact Length:0.323" (8.20mm)
Insulation Height:0.059" (1.50mm)
Contact Shape:Square
Contact Finish - Mating:Gold
Contact Finish Thickness - Mating:30.0µin (0.76µm)
Contact Finish - Post:Tin
Contact Material:Phosphor Bronze
Insulation Material:Liquid Crystal Polymer (LCP)
Features:-
Operating Temperature:-55°C ~ 125°C
Ingress Protection:-
Material Flammability Rating:-
Insulation Color:Black
Current Rating (Amps):3.2A per Contact
Voltage Rating:-
TMM-147-01-S-S is available at GangBo-ic.com, Please review product page below for detailed information, including TMM-147-01-S-S price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for TMM-147-01-S-S to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
