0009571116

0009571116

Image is for reference, please contact us to get the real picture

Part No :

0009571116

Manufacturer
Woodhead - Molex
Description
CONN HEADER VERT 11POS 3.96MM
Catalog
Rectangular Connectors - Headers, Male Pins
Availability
089408 pieces
Shipped from
HK warehouse
Expected Shipping Date
Jun 17 - Jun 21 2025
PDF
0009571116 PDF
Type Description
Series:KK396, 2220
Package:Bulk
Part Status:Obsolete
Connector Type:Header
Contact Type:Male Pin
Pitch - Mating:0.156" (3.96mm)
Number of Positions:11
Number of Rows:1
Row Spacing - Mating:-
Number of Positions Loaded:All
Style:Board to Cable/Wire
Shrouding:Unshrouded
Mounting Type:Panel Mount, Snap-In; Through Hole
Termination:Solder
Fastening Type:Push-Pull
Contact Length - Mating:0.718" (18.24mm)
Contact Length - Post:0.917" (23.29mm)
Overall Contact Length:1.750" (44.45mm)
Insulation Height:0.250" (6.35mm)
Contact Shape:Square
Contact Finish - Mating:Tin
Contact Finish Thickness - Mating:60.0µin (1.52µm)
Contact Finish - Post:Tin
Contact Material:Brass
Insulation Material:Polyamide (PA66), Nylon 6/6
Features:-
Operating Temperature:-
Ingress Protection:-
Material Flammability Rating:UL94 V-2
Insulation Color:Natural
Current Rating (Amps):-
Voltage Rating:-
0009571116 is available at GangBo-ic.com, Please review product page below for detailed information, including 0009571116 price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for 0009571116 to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
