DF14-5P-1.25H(55)

DF14-5P-1.25H(55)

Image is for reference, please contact us to get the real picture

Part No :

DF14-5P-1.25H(55)

Manufacturer
Hirose
Description
CONN HEADER SMD R/A 5POS 1.25MM
Catalog
Rectangular Connectors - Headers, Male Pins
Availability
929592 pieces
Shipped from
HK warehouse
Expected Shipping Date
Jun 28 - Jul 02 2025
PDF
DF14-5P-1.25H(55) PDF
Type Description
Series:DF14
Package:Tube
Part Status:Obsolete
Connector Type:Header
Contact Type:Male Pin
Pitch - Mating:0.049" (1.25mm)
Number of Positions:5
Number of Rows:1
Row Spacing - Mating:-
Number of Positions Loaded:All
Style:Board to Cable/Wire
Shrouding:Shrouded - 4 Wall
Mounting Type:Surface Mount, Right Angle
Termination:Solder
Fastening Type:Push-Pull
Contact Length - Mating:0.086" (2.20mm)
Contact Length - Post:-
Overall Contact Length:-
Insulation Height:0.098" (2.50mm)
Contact Shape:Square
Contact Finish - Mating:Gold
Contact Finish Thickness - Mating:3.90µin (0.099µm)
Contact Finish - Post:Tin-Copper
Contact Material:Brass
Insulation Material:Polyamide (PA), Nylon
Features:Board Guide, Solder Retention
Operating Temperature:-35°C ~ 85°C
Ingress Protection:-
Material Flammability Rating:UL94 V-0
Insulation Color:Beige
Current Rating (Amps):1A
Voltage Rating:150V
DF14-5P-1.25H(55) is available at GangBo-ic.com, Please review product page below for detailed information, including DF14-5P-1.25H(55) price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for DF14-5P-1.25H(55) to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
