2242-2X13G00DT-P

Image is for reference, please contact us to get the real picture

Part No :: 2242-2X13G00DT-P

Manufacturer: Oupiin

Description: PCB SOCKET, DOUBLE ROW, 26 PIN,

Catalog: Rectangular Connectors - Headers, Receptacles, Female Sockets

Availability: 957095 pieces

Shipped from: HK warehouse

Expected Shipping Date: Jun 11 - Jun 15 2025

Type	Description
Series:	2242
Package:	Tape & Reel (TR)
Part Status:	Active
Connector Type:	Socket
Contact Type:	Female Socket
Style:	Board to Board
Number of Positions:	26
Number of Positions Loaded:	All
Pitch - Mating:	0.050" (1.27mm)
Number of Rows:	2
Row Spacing - Mating:	0.050" (1.27mm)
Mounting Type:	Surface Mount
Termination:	Solder
Fastening Type:	Push-Pull
Contact Finish - Mating:	Gold
Contact Finish Thickness - Mating:	Flash
Insulation Color:	Black
Insulation Height:	0.169" (4.30mm)
Contact Length - Post:	-
Operating Temperature:	-65°C ~ 125°C
Material Flammability Rating:	UL94 V-0
Contact Finish - Post:	Gold
Mated Stacking Heights:	-
Ingress Protection:	-
Features:	Pick and Place
Current Rating (Amps):	1A
Voltage Rating:	-

2242-2X13G00DT-P is available at GangBo-ic.com, Please review product page below for detailed information, including 2242-2X13G00DT-P price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for 2242-2X13G00DT-P to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
