CONN PC PIN CIRC 0.025DIA GOLD
8D 1C 1#8 QUAD SKT RECP
FERRITE CORE
Type | Description |
---|---|
Series: | - |
Package: | Bulk |
Part Status: | Active |
Terminal Type: | PC Pin |
Terminal Style: | Single End |
Pin Size - Above Flange: | 0.025" (0.64mm) Dia |
Pin Size - Below Flange: | - |
Length - Above Flange: | 0.126" (3.20mm) |
Length - Below Flange: | 0.125" (3.18mm) |
Length - Overall: | 0.281" (7.14mm) |
Flange Diameter: | 0.078" (1.98mm) |
Mounting Hole Diameter: | 0.062" (1.57mm) |
Mounting Type: | Through Hole |
Termination: | Swage |
Insulation: | Non-Insulated |
Board Thickness: | 0.093" (2.36mm) |
Contact Material: | Brass |
Contact Finish: | Gold |
Contact Finish Thickness: | 10.0µin (0.25µm) |
