IRF3709

IRF3709

Image is for reference, please contact us to get the real picture

Part No :

IRF3709

Manufacturer
IR (Infineon Technologies)
Description
MOSFET N-CH 30V 90A TO220AB
Catalog
Transistors - FETs, MOSFETs - Single
Availability
454445 pieces
Shipped from
HK warehouse
Expected Shipping Date
Jul 04 - Jul 08 2025
PDF
IRF3709 PDF
Type Description
Series:HEXFET®
Package:Tube
Part Status:Obsolete
FET Type:N-Channel
Technology:MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):30 V
Current - Continuous Drain (Id) @ 25°C:90A (Tc)
Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
Rds On (Max) @ Id, Vgs:9mOhm @ 15A, 10V
Vgs(th) (Max) @ Id:3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:41 nC @ 5 V
Vgs (Max):±20V
Input Capacitance (Ciss) (Max) @ Vds:2672 pF @ 16 V
FET Feature:-
Power Dissipation (Max):3.1W (Ta), 120W (Tc)
Operating Temperature:-55°C ~ 150°C (TJ)
Mounting Type:Through Hole
Supplier Device Package:TO-220AB
Package / Case:TO-220-3
IRF3709 is available at GangBo-ic.com, Please review product page below for detailed information, including IRF3709 price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for IRF3709 to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
