Image is for reference, please contact us to get the real picture

Part No :

HCPL2503SV

Manufacturer
Sanyo Semiconductor/ON Semiconductor
Description
OPTOISO 2.5KV TRANS W/BASE 8SMD
Catalog
Optoisolators - Transistor, Photovoltaic Output
Availability
299529 pieces
Shipped from
HK warehouse
Expected Shipping Date
Jun 17 - Jun 21 2025
PDF
HCPL2503SV PDF
Type Description
Series:-
Package:Tube
Part Status:Obsolete
Number of Channels:1
Voltage - Isolation:2500Vrms
Current Transfer Ratio (Min):12% @ 16mA
Current Transfer Ratio (Max):-
Turn On / Turn Off Time (Typ):450ns, 300ns
Rise / Fall Time (Typ):-
Input Type:DC
Output Type:Transistor with Base
Voltage - Output (Max):20V
Current - Output / Channel:8mA
Voltage - Forward (Vf) (Typ):1.45V
Current - DC Forward (If) (Max):25 mA
Vce Saturation (Max):-
Operating Temperature:-55°C ~ 100°C
Mounting Type:Surface Mount
Package / Case:8-SMD, Gull Wing
Supplier Device Package:8-SMD
HCPL2503SV is available at GangBo-ic.com, Please review product page below for detailed information, including HCPL2503SV price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for HCPL2503SV to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
