ISP12DP06NMXTSA1

Image is for reference, please contact us to get the real picture

Part No :: ISP12DP06NMXTSA1

Manufacturer: IR (Infineon Technologies)

Description: MOSFET P-CH 60V 2.8A SOT223-4

Catalog: Transistors - FETs, MOSFETs - Single

Availability: 320132 pieces

Shipped from: HK warehouse

Expected Shipping Date: May 10 - May 14 2025

Type	Description
Series:	OptiMOS™
Package:	Tape & Reel (TR)
Part Status:	Active
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	2.8A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	125mOhm @ 2.8A, 10V
Vgs(th) (Max) @ Id:	4V @ 520µA
Gate Charge (Qg) (Max) @ Vgs:	20.2 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	790 pF @ 30 V
FET Feature:	-
Power Dissipation (Max):	1.8W (Ta), 4.2W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PG-SOT223-4
Package / Case:	TO-261-4, TO-261AA

ISP12DP06NMXTSA1 is available at GangBo-ic.com, Please review product page below for detailed information, including ISP12DP06NMXTSA1 price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for ISP12DP06NMXTSA1 to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
